Water Treatment Chemical Solenoid Metering Pump

  • Water Treatment Chemical Solenoid Metering Pump
  • Water Treatment Chemical Solenoid Metering Pump
  • Water Treatment Chemical Solenoid Metering Pump

Water Treatment Chemical Solenoid Metering Pump

    Payment Type: L/C,T/T,Paypal
    Terms of Trade: FOB
    Min. Order: 1 Bag/Bags
    Delivery Time: 3 Days
    Packaging: Strong carton packing suitable for the long distance transportation.
    Productivity: 2000piece/month
    Brand: AILIPU
    Transportation: Ocean,Air
    Place of Origin: China (Mainland)
    Supply Ability: 2000
    Certificate: ISO9001,CE
    HS Code: 8413502090
    Port: NingBo,Shanghai

Basic Info

Model No.: JCMB55-20/2.5

Product Description

Product Description

JCMB Series are Microprocessor-based digital control solenoid driven metering pumps with simple and stable operation

Applications: Municipal water and wastewater treatment, chlorine dioxide dosing, reverse osmosis, food&beverage pharmaceutical etc.

JCMB45 Model

Model

Max. Flow

Max. Pressure

Pipe Dia. (mm)

Suction Pipe Material

Discharge Pipe Material

JCMB45–3/15

3.0 L/H

15bar

In5.5 Out 9.5

PVC

PE

JCMB45–5/10

5.0 L/H

10bar

In5.5 Out 9.5

PVC

PE

JCMB45–10/5

10 L/H

5bar

In5.5 Out 9.5

PVC

PE


JCMB55 Model

Model

Max. Flow

Max. Pressure

Pipe Dia. (mm)

Suction Pipe Material

Discharge Pipe Material

JCMB55–15/3.2

15 L/H

3.2bar

In6.5 Out 9.5

PVC

PE

JCMB55–20/2.5

20 L/H

2.5bar

In6.5 Out 9.5

PVC

PE

JCMB55–25/2.0

25 L/H

2.0bar

In6.5 Out 9.5

PVC

PE

Solenoid pump outline dimentionSolenoid pump

Products Show


Solenoid pump (4-20mA electric current signal control)

1. High Speed Operation

Up to 400 strokes per minute results in high resolution chemical feed, with the elimination of slug-feed effects

2. Compact Size

JCMB pumps are small, quiet, and light weight

3. Long Lasting Diaphragm

The disphragm is made up by PTFE, which is compatible with all kinds of chemicals. The life of the diaphragm is over 5 years, which 5 times as national standard GB/T7782-2008

4. Strong Power Supply Compatibility

Having power automatic recognition, smooth working stability in AC100-240V, and suitable for 50-60Hz range

5. High Protection Level

JCMB series metering Pump protection level is ip65 and it can function safely under tough environment

6. Double Valve Ball Structure

The precision ball, seat and guide assembly ensure tight sealing to prevent loss of prime

JCMB Series
Solenoid pump manual

JCMB-S

1. Manual flow adjusting

2. Pump On/Off indicator

3. Displayable frequency percentage

Solenoid pump Auto-Adjust (Digital impulse signal control)

JCMB-C Auto-Adjust (Digital impulse signal control)

Two control modes available:

1. Manual

2. Auto: controlled by the signal received (Digital pulse signal)

Solenoid pump Auto-Adjust (4-20mA electric current signal control with Rs485 communication interface)

JCMB-H Auto-Adjust (4-20mA electric current signal control)

Two control modes available:

1. Manual

2. Auto: controlled by the signal received (4-20mA electric current signal)

Solenoid pump Auto-Adjust (Digital impulse signal control feedback)

JCMB-F Auto-Adjust (Digital impulse signal control feedback)

Two control modes available:

1. Manual

2. Auto: controlled by the signal received (Digital pulse signal ) and feedback operating signal for remote control.

Solenoid pump Auto-Adjust (Digital impulse signal control feedback with Rs485 communication interface)

JCMB-CR Auto-Adjust (Digital impulse signal control feedback with Rs485 communication interface)

Two control modes available:

1. Manual

2. Auto: controlled by the signal received (Digital pulse signal ) and feedback operating signal for remote control with Rs485 communication interface by MODBUS protocol.


Solenoid pump Auto-Adjust (4-20mA electric current signal control with Rs485 communication interface)

JCMB-H Auto-Adjust (4-20mA electric current signal control with Rs485 communication interface)

Two control modes available:

1. Manual

2. Auto: controlled by the signal received (4-20mA electric current signal) with Rs485 communication interface: using MODBUS protocol.
